Product Description
Package # s
24T900- Bare machine only
EST900- 35 insulated 5 hose bundled with scuff jacket
Max spray pressure: 3000 psi
Max flow rate: 1 gal/min
Max fluid temperature: 170 °F
Recirculation time to 170 °F: 20 min (70 °F initial material temperature, 5 gal material per tank)
Primary heat: 2760 watts
Boost heat: 1240 watts
Total heat: 4000 watts
Hopper capacity: 6 gal per tank
Max hose length: 105 ft
Dimensions(WxDxH): 29"x36"x46"
Weight: 239 lbs
Recommended chamber sizes: 000. AW2222 and 00, 01 at reduced pressure
Electrical requirements: (2) 15 Amp outlets
-Digital heat controls
' Allows you to enter the exact temperatures you need
' Uses the same circuit boards as a standard Reactor
-Insulated tanks
' Double-wall insulated to retain heat
' Smooth interior lining for easy cleaning
' Improved seal design on lid for better moisture control
-Motor
' Offers 50% more power than the Reactor E-10
' Provides improved spray performance with reduced pressure drop
-Boost heat
' Directs unused power from the motor circuit to additional heater rods
' Additional heater power brings material to desired temperatures faster during recirculation mode
-Single knob motor operation
' Intuitive, easy to use
-Robust hybrid heater
' More power, faster material heating means more uptime
-Low level sensors
' Indicates when material is low (1 gal / 3.8 L remaining)
' No contact with materials - prevents buildup
-Temperature gauges in Y-strainers
' Provides accurate tank temperature readings
-Wide tank opening
' Easy material loading and easy to clean
-Quick knockdown lower pumps
' Easy disassembly and maintenance
-Portable
' Fits through standard doorways
' Plugs into standard 120V or 230V outlets
' Rugged wheels for extreme jobsites
' No need for generator
